Cambium Networks cnWave outdoorový AC/DC napájací zdroj, 60W, 54VDC - N000000L178A

The Cambium Networks cnWave Outdoor AC/DC PSU is a high-performance power supply unit designed for outdoor deployment with cnWave series devices. Delivering 60W of power at 54VDC, it ensures reliable operation in harsh environments with an IP67 rating and wide temperature range.

Advantages

This PSU offers robust protection features including over-voltage, over-current, and short-circuit protection, along with integrated surge protection. Its UV-stabilized weather-resistant enclosure and IP67 rating make it ideal for outdoor installations. The unit supports both wall and pole mounting for flexible deployment.

Suitable for

• Cambium Networks cnWave V5000, V3000, V1000 and other cnWave series devices
• Outdoor wireless access points and backhaul equipment requiring 54VDC power
• Industrial and telecom applications in extreme temperatures (-40°C to 60°C)

Key specifications

• Output Power: 60W
• Output Voltage: 54VDC
• Input Voltage: 90-264VAC, 47-63Hz
• Ingress Protection: IP67
• Operating Temperature: -40°C to 60°C
• Mounting: Wall or pole mount (bracket optional)
• Protection: Over-voltage, over-current, short-circuit, surge

Recommendations

For optimal performance, use with Cambium Networks cnWave devices and ensure proper grounding. The integrated AC input cable simplifies installation; connect the DC output via terminal block or cable gland as per the device requirements.
