Capture Stingray/Manta 120W 24V 5A dodatočný 12V/24V Powered USB napájací adaptér (CA-SP-1010)

The Capture Stingray/Manta 120W Power Adapter (CA-SP-1010) is a high-performance desktop power supply designed for demanding applications such as POS systems, industrial PCs, kiosks, and displays. With a total power output of 120W, it provides a primary 24V DC output at 5A and an additional powered USB output that automatically selects 12V or 24V DC. This dual-output capability makes it ideal for powering devices that require both a main DC supply and a USB-powered peripheral.

Advantages

Reliable and efficient power delivery with over 87% efficiency, passive cooling for silent operation, and comprehensive protection features including over voltage, over current, short circuit, and over temperature. The compact desktop form factor saves space and the LED indicator provides clear power status.

Suitable for

• POS Systems
• Industrial PCs
• Kiosks
• Displays
• Any device requiring 24V DC and powered USB

Key specifications

• Total Power Output: 120W
• Primary Output: 24V DC, 5A
• Secondary Output: Powered USB (12V/24V selectable)
• Input: 100-240V AC, 50/60 Hz
• Input Connector: IEC C6 (Cloverleaf)
• Primary Output Connector: DC Barrel Jack
• Secondary Output Connector: Powered USB Type A
• Efficiency: >87%
• Protection: OVP, OCP, SCP, OTP
• Operating Temperature: 0°C to 40°C
• Cooling: Passive (Fanless)
• LED Indicator: Power Status
• Certifications: CE, FCC, RoHS
• Enclosure: High-impact ABS Plastic
• MTBF: >50,000 hours

Recommendations

For optimal performance, use with devices that require a stable 24V DC supply and a powered USB port. Ensure the input voltage matches your local mains supply. This adapter is not suitable for outdoor use or environments with high humidity.
