DSIT CAT 6 sieťový kábel LSOH S/FTP 30 m biely (DC-S62-300)

Running high-speed data links in offices or industrial spaces often means dealing with cables that are either too stiff, too flammable, or too lossy. The DSIT CAT 6 S/FTP cable solves that with a 30-metre run of screened, foiled twisted-pair construction wrapped in a low-smoke zero-halogen jacket. It delivers 10 Gigabit Ethernet up to 250 MHz, so even bandwidth-hungry applications stay smooth.

Who is it for

Network installers, IT technicians, and facility managers who need a dependable, fire-safe cable for permanent indoor runs. It’s ideal for structured cabling in offices, data centres, schools, and hospitals where building codes demand LSOH materials. If you’re pulling cable through risers, plenums, or crowded conduits, the solid bare-copper conductors and rugged jacket make termination straightforward and reliable.

Main features

• CAT 6 performance with 250 MHz bandwidth and 10GBASE-T support
• S/FTP shielding: individual foil on each pair plus overall braid screen for excellent EMI rejection
• LSOH (Low Smoke Zero Halogen) jacket – emits very little smoke and no corrosive halogens in a fire
• Solid bare copper conductors, 23 AWG, for stable PoE and long-term signal integrity
• 30-metre length, unterminated, ready for custom RJ45 connectors or patch panels
• Compliant with TIA/EIA-568-C.2 and ISO/IEC 11801

Specifications

• Category: CAT 6
• Shielding: S/FTP (Screened/Foiled Twisted Pair)
• Length: 30 m
• Colour: White
• Conductor: Bare copper, solid, 23 AWG
• Pairs: 4 twisted pairs
• Impedance: 100 Ohm
• Outer diameter: approx. 6.0 – 7.5 mm
• Fire safety: IEC 60332-1, IEC 61034-2, IEC 60754-2
• Application: Indoor installation, data networks

Tips

Because the cable is solid-core, avoid sharp bends below the minimum bend radius (typically 4x the outer diameter) to prevent conductor damage. When terminating, use CAT 6 rated connectors and maintain pair twists as close to the termination point as possible. For best performance, test the installed link with a cable certifier to confirm it meets CAT 6 limits.
