DSIT CAT7 S/FTP vonkajší inštalačný kábel 100m plná meď PE plášť čierny Fca CPR

Engineered for 10 Gigabit Ethernet at 600 MHz, this CAT7 S/FTP outdoor cable delivers uncompromising performance in demanding environments. Each of the four twisted pairs is individually foil-shielded (PiMF) and wrapped in an overall braided screen, virtually eliminating alien crosstalk and EMI. The solid 23 AWG bare copper conductors ensure maximum conductivity and support for Power over Ethernet up to 100W, while the rugged PE jacket withstands UV exposure, moisture, and direct burial. With a 100-meter continuous length on a convenient spool, it's the professional's choice for backbone links, campus networks, and industrial installations where reliability is non-negotiable.

Overview

The DSIT CAT7 S/FTP outdoor cable is a premium installation-grade cable designed for permanent links in harsh environments. It meets the stringent requirements of ISO/IEC 11801, EN 50173, and TIA/EIA-568-C.2, ensuring compatibility with all standard Ethernet equipment. The S/FTP construction (Screened/Foiled Twisted Pair) provides superior shielding compared to UTP or F/UTP cables, making it ideal for areas with high electromagnetic interference, such as near power lines, machinery, or radio transmitters. The solid bare copper conductors (AWG23) offer lower attenuation and better heat dissipation than stranded or CCA alternatives, enabling reliable 10GBASE-T operation over the full 100-meter channel length.

What stands out

• 10 Gigabit Ethernet support up to 100 meters with 600 MHz bandwidth
• S/FTP shielding with individual pair foils and overall braid for maximum noise immunity
• Solid 23 AWG bare copper conductors for excellent signal integrity and PoE capability
• UV-resistant PE jacket rated for outdoor use and direct burial
• CPR fire classification Fca (EN 50575) for construction product compliance
• 100-meter spool for convenient pull-box installation

Technical details

• Cable category: CAT7
• Shielding: S/FTP (PiMF)
• Conductor: Solid bare copper, AWG23
• Jacket: Polyethylene (PE), black
• Impedance: 100 Ohm
• Bandwidth: 600 MHz
• Data rate: 10 Gbps (10GBASE-T)
• Length: 100 m
• Outer diameter: approx. 7.8 mm
• Operating temperature: -20°C to +60°C
• Installation temperature: 0°C to +50°C
• Standards: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2
• CPR class: Fca

Our verdict

For outdoor or industrial network runs where interference and weather are concerns, this DSIT cable is a top-tier choice. The combination of solid copper, S/FTP shielding, and a rugged PE jacket ensures long-term reliability and full 10G performance. While it's not halogen-free, its Fca rating is acceptable for outdoor and non-plenum indoor applications. The 100m spool provides excellent value for professional installers.
