EFB I-V(ZN)H Simplex OM4 1G (1x1) Dca 150N LSZH tyrkysový 2.8mm

The EFB I-V(ZN)H Simplex OM4 fiber optic cable is a high-performance indoor cable designed for reliable data transmission in structured cabling systems. With its OM4 multimode fiber, it supports high-bandwidth applications up to 100 Gbps over short distances. The cable features a compact 2.8 mm diameter, LSZH jacket, and turquoise color, making it ideal for use in data centers, enterprise networks, and telecommunications rooms.

Advantages

This cable offers excellent fire safety with CPR class Dca-s2,d2,a1 and low smoke zero halogen materials, ensuring minimal toxic emissions in case of fire. The 150 N tensile strength provides robustness during installation, while the tight buffer construction ensures easy termination and connectorization. The OM4 fiber delivers high modal bandwidth (4700 MHz*km at 850 nm) for 10/40/100 GbE applications.

Suitable for

• Data center backbone cabling
• Enterprise network horizontal and backbone
• Telecommunications rooms and closets
• High-speed network connections (10G, 40G, 100G)

Key specifications

• Fiber type: Multimode OM4 (50/125 µm)
• Fiber count: 1 (Simplex)
• Cable construction: I-V(ZN)H (indoor, non-metallic, halogen-free)
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Jacket color: Turquoise
• Outer diameter: 2.8 mm
• CPR fire class: Dca-s2, d2, a1
• Tensile strength: 150 N
• Core diameter: 50 µm
• Cladding diameter: 125 µm
• Effective modal bandwidth (850 nm): 4700 MHz·km
• Overfilled launch bandwidth (1300 nm): 500 MHz·km
• Maximum attenuation (850 nm): 2.3 dB/km
• Maximum attenuation (1300 nm): 0.6 dB/km
• Operating temperature: -20°C to +60°C
• Minimum bend radius (installation): 28 mm
• Minimum bend radius (operation): 14 mm

Recommendations

For optimal performance, use with OM4-rated connectors and ensure proper cable management to maintain bend radius. Suitable for indoor installations where fire safety and high bandwidth are required.
