EXSYS EX-6972 DIN lištový napájací zdroj 36W 12V 3A AC 100-240V

Industrial control panels often demand a compact, reliable power source that mounts cleanly onto a DIN rail. The EXSYS EX-6972 delivers exactly that: a 36-watt DIN rail power supply converting AC 100–240V input into a stable 12V DC output at up to 3A. Its plastic housing and screw terminal connections make it a practical choice for automation, building control, and instrumentation systems.

Key specifications

• Input voltage: AC 100–240V, 50/60 Hz
• Output voltage: DC 12V
• Output current: 3A
• Output power: 36W
• Mounting: DIN rail (TS-35/7.5 or TS-35/15)
• Efficiency: up to 85%
• Protection: short circuit, overload, overvoltage
• Operating temperature: -20°C to +70°C
• Cooling: free air convection
• Certifications: CE, RoHS

Why choose it

The EX-6972 saves space and simplifies wiring in crowded enclosures. Its wide input range handles fluctuating mains voltages, while built-in protections safeguard connected equipment. Convection cooling means no fan noise or maintenance, and the screw terminals ensure secure, vibration-resistant connections.

Ideal use cases

• Powering sensors, relays, and controllers in industrial cabinets
• Building automation and HVAC control panels
• Small-scale machinery and test equipment
• Retrofit projects requiring a DIN rail mount

Good to know

The unit operates reliably in humid environments (20–90% RH non-condensing) and can be stored from -40°C to +85°C. Its plastic enclosure is lightweight yet durable, and the standard DIN rail format allows tool-free snap-on installation. Always verify that the total load does not exceed 36W to maintain full protection.
