HEINRICH KOPP 350912048 Rozvodná krabica, IP54, 7 káblových vstupov, sivá

Surface-mount distribution box with 7 flexible membrane cable entries for indoor and sheltered outdoor use.

Advantages

Snap-on lid enables quick access for installation and maintenance. Halogen-free polypropylene housing with impact resistance IK07 and glow wire rating 650 °C.

Suitable for

• Electrical distribution in residential and commercial buildings
• Protected outdoor areas such as carports or covered terraces
• Junction and connection points for cables from 3 mm to 14 mm diameter

Key specifications

• Protection class: IP54
• Material: Polypropylene (PP), grey (RAL 7035)
• Number of cable entries: 7
• Cable entry type: Flexible membrane entries
• Lid type: Snap-on lid
• Mounting type: Surface mount
• Rated insulation voltage (Ui): 400 V
• Rated impulse withstand voltage (Uimp): 2.5 kV
• Glow wire test temperature: 650 °C
• Operating temperature range: -25 °C to +40 °C
• Impact resistance: IK07
• Internal dimensions (L x W x H): 77 x 77 x 35 mm
• Cable entry diameter range: 3 - 14 mm
• Standards/Certifications: VDE, CE
• Number of terminals: None (empty box)
• Application: Indoor and sheltered outdoor

Recommendations

For installations requiring a compact, robust enclosure with quick cable entry, this box provides reliable protection and easy handling.
