helos optický OS2 patch kábel Uniboot LC/LC Duplex 9/125 µm, LSZH, 2,0 mm, žltý, 10 m (373369)

The Helos LWL Patch Cable Uniboot LC/LC Duplex 9/125µm OS2 in black, 10.0 m long, is a single-mode fiber patch lead designed for high-speed and long-distance optical links. It uses LC duplex connectors in a uniboot format that reduces cable bundle diameter and simplifies routing in dense installations. The cable conforms to 9/125µm OS2 single-mode specifications to support low attenuation and stable signal transmission for backbone and interconnect applications.

Advantages

The uniboot LC/LC duplex design minimizes space requirements in racks and patch panels while keeping both fibers in a single, easily managed jacket. The 9/125µm OS2 fiber provides low insertion loss and high return loss properties suitable for long-reach links. The 10.0 m length in a robust black jacket offers flexibility for data center or telecommunications layouts and reduces the need for intermediate splices or additional patching. LC connectors provide a compact connection interface that is widely compatible with optical equipment.

Suitable for

• Data center interconnects and rack-to-rack patching
• Telecommunications backbone optical links
• Server farms and SAN (Storage Area Network) optical connections
• Optical patch panels and high-density fiber installations

Key specifications

• Fiber type: single-mode 9/125µm (OS2)
• Connector type: LC/LC duplex uniboot
• Length: 10.0 meters
• Color: black
• Attenuation: low insertion loss suitable for long-distance links
• Construction: duplex uniboot jacket for reduced diameter and easy routing

How to use

Route the uniboot cable through cable managers or trays to the desired patch panel or device ports. Align and insert the LC connectors into compatible LC duplex ports until they click into place. Ensure fiber ends are clean before connection to maintain low insertion loss; use appropriate fiber cleaning tools if necessary. Avoid sharp bends and maintain the cable's minimum bend radius to prevent increased attenuation. For disconnection, depress the connector latch and gently withdraw the connector.

Recommendations

Store unused ends with protective dust caps and avoid exposure to dirt or moisture. When installing in high-density environments, use cable management accessories to prevent kinking and to maintain minimum bend radius; perform optical loss testing after installation to verify link performance.
