INTEL Wi‑Fi 6 AX201 – sieťová karta – M.2 2230 (CNVio2) – 802.11ac Bluetooth 5.0 802.11ax

The Intel Wi-Fi 6 AX201 Internal WLAN is a dual-band 2x2 wireless network card that supports the Wi‑Fi 6 (802.11ax) standard and offers up to 2400 Mbit/s maximum data rate. Designed for installation in compatible laptops and desktops, the AX201 improves spectral efficiency and multi-user performance by using technologies such as OFDMA for simultaneous low-data-rate transmissions from multiple devices.

Advantages

The Intel Wi‑Fi 6 AX201 provides higher throughput and better network efficiency compared with previous Wi‑Fi generations, with dual-band operation for 2.4 GHz and 5 GHz networks and a 2x2 antenna configuration for improved signal quality. Support for the 802.11ax standard and features like OFDMA reduce latency and increase capacity in crowded wireless environments.

Suitable for

• Upgrading internal Wi‑Fi in laptops and mini‑PCs that accept M.2 2230/1216 form‑factor WLAN modules
• High‑speed internet access, streaming video and online meetings
• Home and small‑office networks with multiple simultaneous users

Key specifications

• Standard: IEEE 802.11ax (Wi‑Fi 6)
• Max data rate: up to 2400 Mbit/s
• Bands: Dual‑band (2.4 GHz and 5 GHz)
• Antenna: 2x2 MIMO
• Form factor: Internal M.2 WLAN module (check device compatibility)
• Manufacturer: Intel, MPN: AX201.NGWG.NVW, EAN: 5032037183925

How to use

Power off the computer and open the service panel according to the device manufacturer’s instructions. Locate the M.2 WLAN slot and insert the Intel AX201 module into the slot at the appropriate angle, then secure it with the retaining screw. Reattach any antenna cables if required and close the panel. Install or update drivers for the AX201 from the computer manufacturer or Intel's support site to ensure full functionality.

Recommendations

Ensure your system BIOS and operating system support Intel AX201 modules and that the device has the correct M.2 slot and antenna connections. For best performance, use the card on both 2.4 GHz and 5 GHz bands where available, and keep drivers up to date.
