JUNG LC 1520 205 SCHUKO zásuvka 16 A 250 V, duroplast lakovaný, séria LS, gris clair 31 (32013)

SCHUKO socket outlet with hinged cover and labeling field, providing reliable power distribution in flush-mounted installations. The cover protects against dust and splashing water when closed, making it suitable for use in protected outdoor areas and damp rooms.

Advantages

Hinged cover with labeling field for clear identification of circuits. Halogen-free thermoplastic housing in alpine white. Screw terminals accept rigid conductors up to 2.5 mm². Designed for JUNG LS-Design range.

Suitable for

• Flush-mounted installations in residential and commercial buildings
• Protected outdoor areas and damp rooms (IP44 with cover closed)
• Use with JUNG LS-Design frames and covers

Key specifications

• Socket type: SCHUKO (Type F)
• Rated voltage: 250 V AC
• Rated current: 16 A
• Mounting type: Flush-mounted (Unterputz)
• Connection type: Screw terminals
• Material: Thermoplastic (PC)
• Colour: Alpine White
• Number of sockets: 1-gang
• Terminal capacity: up to 2.5 mm² rigid conductors
• Overvoltage category: III
• Degree of pollution: 2
• Operating temperature: -5 to +40 °C
• Impact resistance: IK05
• Certification: VDE

Recommendations

Combine with JUNG LS-Design frames in matching alpine white for a uniform appearance. Suitable for new installations and retrofits.
