Káblová odbočka Televes VS20WD

The Televes VS20WD is a cable combiner engineered to work across a frequency range of 950–2150 MHz. With compact dimensions (85 x 25 x 70 mm) and a grey housing, this device fits into standard coaxial installations and accepts F-type connectors for straightforward integration into existing cable systems. The unit combines multiple signals into a single output while aiming to preserve signal integrity within its specified frequency band.

Advantages

The combiner offers a compact form factor that simplifies installation in racks, junction boxes, or wall-mounted setups. It supports the common satellite and broadband frequency band used in consumer and professional applications, and its F-connector interfaces ensure wide compatibility with standard coaxial cables and accessories. The device is designed for low insertion loss across its operating range to maintain signal quality during combination.

Suitable for

Key specifications

How to use

Install the Televes VS20WD by connecting each input cable to the designated F connectors and securing the combined output to the downstream device or distribution line. Ensure all connections are tightened to prevent signal leakage and verify cable continuity and shielding integrity before powering any active equipment. Mount the combiner in a location that provides easy access for inspection and minimizes cable strain.

Recommendations

Use suitable quality coaxial cables and maintain proper connector torque to achieve optimal performance. Avoid installing the combiner in wet or excessively dusty environments unless adequate environmental protection is provided. For best results, verify the combined signal levels with appropriate measurement tools to prevent overload or insufficient signal at the receiving equipment.
