Microconnect FIB121001 InfiniBand/optický kábel 1 m ST SC žltý

The Microconnect FIB121001 InfiniBand fibre optic cable is a 1 m single-mode patch cable with ST and SC connectors, designed for high-speed data transmission in enterprise networks, telecom rooms, server farms and cloud storage environments. It uses OS2 fibre with a 9 µm core diameter and a yellow LSZH jacket, and is suitable for 1G/10G/40G/100G Ethernet links and InfiniBand connections requiring single-mode performance.

Advantages

The cable supports long-distance transmission (up to 10 km at 1310 nm and up to 40 km at 1550 nm), uses industry-standard OS2 single-mode fibre for low attenuation, and is built with an LSZH jacket compliant with common standards such as IEC and Telcordia. The combination of ST and SC connectors provides compatibility with a wide range of equipment and patch panels.

Suitable for

• Enterprise network backbone links
• Telecom rooms and equipment racks
• Server farms and data centre interconnects
• Cloud storage networks and InfiniBand connections
• High-speed Ethernet links (1G/10G/40G/100G)

Key specifications

• Length: 1 m
• Fibre type: OS2 (single-mode)
• Core diameter: 9 µm
• Connectors: ST to SC
• Jacket: LSZH (yellow)
• Standards: conforms to IEC / Telcordia / EIA‑TIA guidelines
• Transmission reach: up to 10 km @ 1310 nm, up to 40 km @ 1550 nm
• Brand / MPN: MicroConnect / FIB121001

How to use

Inspect connectors and ports for contamination before installation. Align the ST connector and the SC connector with their corresponding receptacles and insert until secured. Route the cable avoiding sharp bends and excessive tension; follow recommended minimum bend radius specified by the equipment or fibre manufacturer. Verify link status and optical power levels after installation.

Recommendations

Use in indoor environments and structured cabling runs; avoid exposure to direct sunlight or prolonged outdoor use without appropriate protective conduit. For safety and compliance, store and handle the LSZH cable in accordance with site regulations and industry best practices.
