MITON MT-P1280-D46-B hermetické vonkajšie puzdro 120x80x46mm čierne

The MITON MT-P1280-D46-B is a robust hermetic outdoor enclosure designed to protect sensitive electronic components in harsh environments. Manufactured from high-quality ABS plastic, this enclosure offers excellent durability and UV resistance, ensuring long-lasting performance in outdoor installations.

Advantages

With an IP65 rating, the MT-P1280-D46-B provides complete protection against dust ingress and low-pressure water jets, making it ideal for outdoor use. The integrated rubber gasket ensures a reliable seal, while the four-screw lid fastening guarantees secure closure. The enclosure includes two pre-installed M16 cable glands for easy cable entry and management.

Suitable for

• Outdoor electronic installations requiring weatherproof protection
• Telecommunications and networking equipment
• Security systems and access control components
• Industrial control and monitoring devices

Key specifications

• Material: ABS Plastic
• IP Rating: IP65
• External Dimensions (L x W x H): 120 x 80 x 46 mm
• Internal Dimensions (L x W x H): 114 x 74 x 40 mm
• Color: Black
• Lid Fastening: 4x Screws
• Seal Material: Rubber Gasket
• Cable Glands Included: 2x M16
• Number of Cable Entries: 2
• Mounting Type: Wall Mount (Integrated Lugs)
• Operating Temperature Range: -25°C to +70°C
• UV Resistance: Yes
• Internal Mounting Features: Mounting bosses for PCB/DIN rail

Recommendations

For optimal installation, ensure the enclosure is mounted on a flat, clean surface using the integrated wall lugs. Use appropriate cable glands for your cable diameters and seal unused entries to maintain IP65 protection. The internal mounting bosses allow for easy installation of PCBs or DIN rail components.
