MITON MT-P130 univerzálne puzdro na omietku, svetlosivá (RAL 7035), 130x130x70mm, IP55, ABS

The MITON MT-P130 is a robust universal surface mount enclosure designed for electrical, electronic, network, and automation applications. Manufactured from high-quality ABS plastic with a light grey (RAL 7035) finish, this IP55-rated enclosure offers reliable protection against dust and water jets. Its screw-on lid with four plastic screws ensures secure closure, while the pre-marked knockouts allow for easy cable entry. The enclosure is UV-resistant and features an IK07 impact rating, making it suitable for both indoor and outdoor use.

Advantages

Durable ABS construction with UL94-V0 flammability rating ensures safety and longevity. The IP55 ingress protection and IK07 impact resistance provide excellent protection in demanding environments. The polyurethane gasket maintains a tight seal, and the UV-resistant material prevents degradation from sunlight. Easy to install with surface mounting and pre-marked knockouts for M20/M25 glands.

Suitable for

• Electrical junction boxes
• Network and automation enclosures
• Control and distribution boxes
• Outdoor and industrial applications

Key specifications

• Material: ABS Plastic
• Colour: Light Grey (RAL 7035)
• IP Rating: IP55
• External Dimensions: 130 x 130 x 70 mm
• Internal Dimensions: Approx. 122 x 122 x 65 mm
• Lid Type: Screw-on with 4 plastic screws
• Impact Resistance: IK07
• Flammability Rating: UL94-V0
• UV Resistance: Yes
• Gland Entries: 4x pre-marked knockouts
• Seal Material: Polyurethane Gasket
• Operating Temperature: -25°C to +60°C
• Wall Thickness: Approx. 3 mm
• Compliance: CE, RoHS

Recommendations

For optimal installation, use appropriate cable glands (not included) to maintain IP55 protection. Ensure the mounting surface is clean and dry before installation. This enclosure is ideal for protecting sensitive electronic components in harsh environments.
