MITON MT-P134 hermetická prípojná krabica IP55 100x100x50mm svetlosivá

The MITON MT-P134 is a high-quality hermetic junction box designed for reliable outdoor and indoor cable connections. Manufactured from durable ABS plastic with an IP55 rating, it provides excellent protection against dust and water jets, making it ideal for antenna, CCTV, and electrical installations.

Advantages

This junction box offers robust UV resistance and self-extinguishing flame retardancy, ensuring long-lasting performance in harsh environments. The screw-on lid with rubber/silicone gasket guarantees a secure seal, while the knock-out cable entries allow for easy customization.

Suitable for

• Outdoor and indoor cable connections
• Antenna and CCTV installations
• Electrical junction and distribution points
• Mounting PCBs or DIN rails via internal bosses

Key specifications

• Product Type: Hermetic Junction Box
• Material: ABS Plastic
• IP Rating: IP55
• Colour: Light Grey
• External Dimensions (L x W x H): 100 x 100 x 50 mm
• Internal Dimensions (L x W x H): 90 x 90 x 45 mm
• Number of Cable Entries: 4 (knock-out type)
• Lid Fastening: 4x Screw-on
• UV Resistance: Yes
• Operating Temperature: -25°C to +60°C
• Flame Retardancy: Self-extinguishing
• Impact Resistance: IK07
• Corrosion Resistance: Yes
• Standards Compliance: CE, RoHS

Recommendations

For optimal performance, ensure the gasket is properly seated before closing the lid. Use appropriate cable glands for sealed entry. This box is suitable for wall mounting via external lugs.
