MITON MT-P204W rozvodná krabica na omietku IP65 biela

The MITON MT-P204W is a robust surface mount junction box designed for outdoor electrical installations, CCTV, and network equipment. Manufactured from high-quality ABS plastic with UV resistance and IP65 protection, it ensures reliable performance in harsh environments. The box features four pre-marked cable entries compatible with flexible glands/grommets, four internal mounting posts for PCB or DIN rail mounting, and a screw-fastened lid with four screws for secure closure.

Advantages

Durable and weatherproof with IP65 rating and IK07 impact resistance. Halogen-free and UL94-V2 rated for safety. Easy to install with pre-marked knockouts and internal mounting points. Suitable for a wide range of applications including outdoor junction boxes, network outlet boxes, and mounting enclosures.

Suitable for

• Outdoor electrical installations
• CCTV and network equipment enclosures
• Junction and connection boxes
• Surface mount applications

Key specifications

• Material: ABS Plastic
• Colour: White
• IP Rating: IP65
• Mounting Type: Surface Mount
• Lid Fastening: 4 Screws
• External Dimensions (L x W x H): 100 x 100 x 40 mm
• Internal Dimensions (L x W x H): Approx. 94 x 94 x 35 mm
• Number of Cable Entries: 4 (pre-marked/knockout)
• Cable Entry Type: Flexible Gland/Grommet Compatible
• UV Resistance: Yes
• Operating Temperature: -25°C to +60°C
• Impact Resistance: IK07
• Flammability Rating: UL94-V2
• Internal Mounting Points: 4 posts for PCB/DIN rail mounting
• Halogen-Free: Yes
• Certifications: CE, RoHS
• Wall Thickness: Approx. 2.5 mm

Recommendations

For optimal performance, use with appropriate cable glands or grommets. Ensure proper sealing of cable entries to maintain IP65 rating. Suitable for indoor and outdoor use where protection against dust and water jets is required.
