Napájací adaptér MEAN WELL SBTN01L-15 1 W 15 V 4.5-5.5 V

The MEAN WELL SBTN01L-15 is a compact DC-DC converter designed for PCB mounting. It accepts a 4.5–5.5 V DC input and provides a regulated 15 V DC output with output current range 0.007–0.07 A, delivering up to 1 W of output power. This SMD-packaged module is RoHS compliant and intended for low-power voltage conversion on printed circuit boards.

Advantages

The SBTN01L-15 offers a small footprint suitable for surface-mount assembly, predictable 15 V output from a 4.5–5.5 V input range, and low-power operation up to 1 W. Its SMD package simplifies automated PCB assembly and the RoHS compliance meets environmental requirements.

Suitable for

• Powering low-current circuitry that requires 15 V from a 5 V rail
• Embedded systems and sensor modules with limited power budgets
• PCB designs where space is constrained and SMD parts are preferred

Key specifications

• Manufacturer: mean well
• Model (MPN): SBTN01L-15
• Input voltage: 4.5–5.5 V DC
• Output voltage: 15 V DC
• Output current: 0.007–0.07 A
• Output power: 1 W
• Package: SMD / PCB mount
• RoHS: compliant
• EAN: 4021087041973

How to use

Mount the SBTN01L-15 on the PCB according to the manufacturer’s recommended land pattern for SMD components, ensuring correct input and output polarity and adequate soldering. Provide a stable 4.5–5.5 V DC input source capable of supplying the converter’s input requirements. Connect the 15 V output to the target circuit, observing the device’s maximum output current of 0.07 A. Follow standard ESD precautions when handling the SMD module.
