Renkforce PCIe na Mini PCI Express adaptérová karta RF-DT-134B RF-4758075

Most desktop motherboards lack a native Mini PCIe slot, leaving compact expansion cards unusable outside laptops or embedded systems. The Renkforce RF-DT-134B closes this gap with a straightforward PCIe x1 to Mini PCIe bridge that accepts both full-size and half-size modules. It is fully passive and OS-independent, so no driver installation is required for the adapter itself—the connected card simply appears as a normal PCIe device to the system.

Highlights

• Converts a standard PCIe x1 slot into a Mini PCIe slot for mSATA SSDs, WLAN, WWAN, and Bluetooth modules
• Supports full-size and half-size Mini PCIe cards with a standard-profile metal bracket
• Optional 6-pin PCIe power input for auxiliary power to high-draw Mini PCIe devices
• Backward compatible with PCIe 1.0, 2.0, and 3.0 slots (x1, x4, x8, x16)
• Driverless, OS-independent adapter—works with Windows, Linux, and other systems

In daily use

Install the RF-DT-134B into any free PCIe slot, secure the bracket, and mount your Mini PCIe card using the included screws. The adapter routes both data and power through the PCIe bus, and the 6-pin connector can be used when the Mini PCIe card demands more than the slot provides. This makes it ideal for repurposing laptop wireless cards, adding mSATA storage, or testing embedded modules on a desktop platform.

Full specifications

• Host interface: PCI Express x1 (compatible with x4, x8, x16 slots)
• Device interface: Mini PCI Express slot (full-size and half-size)
• Power input: 1x 6-pin PCIe power connector (optional)
• Supported Mini PCIe card types: mSATA SSD, WLAN, WWAN, Bluetooth
• PCIe standard: PCIe 1.0, 2.0, 3.0 compatible
• Connector type (host): PCIe x1 male
• Connector type (device): Mini PCIe female
• LED indicators: No
• Operating system compatibility: OS independent (driverless)
• Material: PCB, metal bracket
• Included accessories: Mounting screws
• Bracket type: Standard profile

Final note

The Renkforce RF-DT-134B is a practical tool for system builders, repair technicians, and tinkerers who need to bridge the gap between desktop PCIe and the Mini PCIe ecosystem without complex adapters or software.
