RITTO APC nerezové tlačidlo s označovacím štítkom RGE1274439

Engineered for demanding environments, this RITTO push-button delivers 10,000,000 mechanical cycles and 1,000,000 electrical cycles, ensuring reliable operation in industrial and building automation applications.

Overview

The RITTO APC Stainless Steel Push-button with Nameplate RGE1274439 is a flush-mount momentary switch with a green actuator and a robust stainless steel bezel. Designed for 22 mm mounting holes, it features a single normally open (NO) contact and screw clamp terminals for secure wiring.

What stands out

• Stainless steel bezel for corrosion resistance and durability
• Flush actuator with spring return (momentary) action
• High mechanical durability: 10,000,000 cycles
• Wide operating temperature range: -40 to 70 °C
• Screw clamp terminals for easy and secure connection

Technical details

• Product type: Push button
• Actuator type: Flush, spring return (momentary)
• Actuator colour: Green
• Contact configuration: 1 normally open (NO)
• Bezel material: Stainless steel
• Mounting diameter: 22 mm
• Connection type: Screw clamp terminals
• Rated insulation voltage (Ui): 600 V (IEC 60947-1)
• Rated impulse withstand voltage (Uimp): 6 kV (IEC 60947-1)
• Operating temperature: -40 to 70 °C
• Storage temperature: -40 to 70 °C

Our verdict

A robust and reliable push-button for industrial control panels, with a stainless steel bezel and high durability ratings.
