Siemens 5SV3111-6 SENTRON RCCB 25A 30mA Type A 2-pólový 230V 10kA biela

The Siemens 5SV3111-6 is a high-quality Residual Current Circuit Breaker (RCCB) from the SENTRON series, designed for reliable protection against electric shock and fire hazards. This 2-pole device features a rated current of 25 A and a rated residual current of 30 mA, making it ideal for standard residential and commercial applications. With a short-circuit withstand capacity of 10 kA and Type A sensitivity, it detects both AC and pulsating DC fault currents. The compact design occupies 2 modular spaces and mounts easily on a 35 mm DIN rail. Its white housing (RAL 9003) ensures a clean, professional look in any distribution board.

Advantages

• Enhanced safety with 30 mA residual current protection
• Type A sensitivity for universal fault detection
• High 10 kA short-circuit withstand capacity
• Easy DIN rail installation with screw terminals
• Reliable Siemens SENTRON quality

Suitable for

• Residential electrical installations
• Commercial buildings
• Industrial control panels
• Protection of circuits with electronic loads

Key specifications

• Brand: Siemens
• Model: 5SV3111-6
• Product Type: Residual Current Circuit Breaker (RCCB)
• Series: SENTRON
• Number of Poles: 2-pole
• Rated Current (In): 25 A
• Rated Residual Current (IΔn): 30 mA
• Type of Residual Current: Type A
• Rated Voltage (Ue): 230 V AC
• Frequency: 50/60 Hz
• Short-circuit Withstand Capacity (Inc): 10 kA
• Surge Current Withstand Capacity: 1 kA
• Mounting Type: DIN Rail (35 mm)
• Modular Spacings: 2
• Degree of Protection: IP20 (terminals), IP40 (installed)
• Operating Temperature Range: -25 to +45 °C
• Terminal Type: Screw Terminals
• Terminal Capacity (Solid): 0.75 - 35 mm²
• Terminal Capacity (Stranded): 0.75 - 25 mm²
• Mechanical Service Life: 10,000 switching cycles
• Electrical Service Life: 10,000 switching cycles
• Color: White (RAL 9003)

Recommendations

For optimal protection, pair this RCCB with a compatible MCB from the Siemens SENTRON range. Ensure proper installation by a qualified electrician.
