Synergy 21 LED flexibilný pásik COB - RGB-W Pixel DC24V WS2814F IP20 2m

The Synergy 21 LED Flex Strip COB RGB-W Pixel is a high-performance, individually addressable LED strip designed for creative lighting projects. Featuring Chip-on-Board (COB) technology, it delivers smooth, uniform light with no visible dots, making it ideal for architectural accents, signage, and decorative installations. With 120 pixels per 2-meter strip (60 pixels/meter), each pixel can be controlled independently for stunning RGB-W color effects, including a dedicated white LED for true white illumination.

Advantages

COB technology ensures a seamless light line without hotspots, while the WS2814F IC allows for precise pixel control. The 24V DC operation reduces voltage drop over longer runs, and the 3M adhesive backing simplifies installation. Full-range dimming via compatible controllers offers versatile brightness adjustment.

Suitable for

• Architectural lighting (cove, under-cabinet, accent)
• Retail displays and signage
• Event and stage lighting
• DIY smart home projects
• Indoor decorative lighting

Key specifications

• Product Type: LED Flex Strip
• LED Technology: COB (Chip-on-Board)
• Color Output: RGB-W (Red, Green, Blue + Dedicated White)
• Addressability: Individually Addressable Pixels
• Control IC: WS2814F
• Operating Voltage: DC 24V
• Strip Length: 2 meters
• IP Rating: IP20 (Indoor Use Only)
• Number of Pixels: 120 pixels (60 pixels/meter)
• Power Consumption: Approx. 36W (18W/meter max)
• Beam Angle: 120°
• Cuttable: Yes, at marked intervals (approx. every 16.67mm)
• Adhesive Backing: Yes, 3M self-adhesive tape
• Dimmability: Full range dimming via compatible controller
• Operating Temperature: -20°C to +50°C
• Lifespan: >50,000 hours
• CRI (White Component): >80 Ra
• Connectivity: 4-pin connector (Data, Backup Data, VCC, GND)
• White Color Temperature: Dedicated White LED (CCT not specified)
• PCB Width: 10mm

Recommendations

For best results, use with a compatible 24V RGB-W pixel controller and power supply. Ensure proper ventilation and avoid exposure to moisture. Cut only at designated cut lines to maintain functionality.
