SYNERGY21 Prepojovací kábel 1m červený 4mm (S21-COMP-00363)

The SYNERGY21 Connection Cable (S21-COMP-00363) is a high-quality 1-meter solar cable designed for reliable DC power transmission in photovoltaic systems. With a 4 mm² cross-section and robust XLPE insulation, this single-core cable ensures efficient energy transfer and long-lasting performance in demanding outdoor environments.

Advantages

This cable offers excellent UV and weather resistance, making it ideal for outdoor installations. Its tinned copper conductor provides superior corrosion resistance and conductivity. The halogen-free, flame-retardant jacket enhances safety, while the flexible design simplifies routing and installation.

Suitable for

• Photovoltaic (PV) systems
• DC power distribution
• Solar panel connections
• Battery banks and inverters

Key specifications

• Length: 1 meter
• Conductor cross-section: 4 mm²
• Colour: Red
• Conductor material: Tinned copper
• Insulation material: XLPE (cross-linked polyethylene)
• Rated voltage: 1000 V DC / 600 V AC
• Rated current: approx. 30-40 A
• Operating temperature: -40°C to +90°C
• UV and weather resistant
• Flame retardant (IEC 60332-1-2)
• Halogen-free
• Outer diameter: approx. 5.5-6.5 mm
• Standard compliance: EN 50618

Recommendations

For optimal performance, use this cable with compatible PV connectors or terminals. Ensure proper strain relief and protection against mechanical damage. Suitable for both residential and commercial solar installations.
