Telegärtner SC Duplex spojka MM OM4 fialová J08081A0040

The Telegärtner SC Duplex Coupler MM OM4 Violet J08081A0040 is a high-performance fiber optic adapter designed for reliable connections in multimode networks. Manufactured by Telegärtner, a trusted name in connectivity solutions, this coupler ensures low insertion loss and high return loss, making it ideal for demanding applications.

Advantages

This SC duplex coupler offers exceptional durability with over 500 mating cycles, ensuring long-term reliability. The zirconia ceramic sleeve provides precise alignment for optimal signal transmission. Its violet housing allows for easy identification in patch panels and distribution boxes.

Suitable for

• Fiber optic patch panels
• Wall outlets
• Distribution boxes
• Data centers and telecommunications rooms

Key specifications

• Connector Type: SC Duplex
• Fiber Compatibility: Multimode (MM) OM4
• Insertion Loss (Max.): 0.3 dB
• Return Loss (Min.): 30 dB
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Mating Durability: > 500 cycles
• Standards: IEC 61754-4, TIA/EIA-604-3
• Housing Material: PBT (Polybutylene Terephthalate)
• RoHS Compliant: Yes
• Halogen-free: Yes

Recommendations

For optimal performance, pair this coupler with Telegärtner patch cables and connectors. Ensure proper cleaning before installation to maintain low insertion loss.
