ALLNET ALL-BRICK-0011 tranzistorový modul 1,5 A

The ALLNET ALL-BRICK-0011 is a high-quality transistor module designed for electronic switching applications. Part of the ALL-BRICK system, this module provides reliable control for loads such as motors, LEDs, and relays. With a maximum collector current of 1.5 A and compatibility with 3.3V/5V logic, it is an ideal building block for prototyping and embedded systems.

Advantages

Easy plug-and-play integration with ALL-BRICK baseboards. Compact design saves space on breadboards or PCBs. RoHS compliant for environmental safety.

Suitable for

• Motor control circuits
• LED driving applications
• Relay switching
• General purpose load switching
• Educational projects and prototyping

Key specifications

• Module Type: Transistor Module
• Series: ALL-BRICK
• Transistor Type: Bipolar Junction Transistor (BJT)
• Max Collector Current (Ic): 1.5 A
• Operating Voltage: 3.3V / 5V (System Dependent)
• Input Interface: Digital (Control Signal)
• Output Interface: Power Switching (Load)
• Connector Type: ALL-BRICK Standard Pin Header
• Number of Channels: 1
• Mounting Type: Plug-in Module

Recommendations

For best performance, use with ALLNET ALL-BRICK baseboards and ensure proper current limiting for the load. Suitable for both hobbyist and industrial applications.
