BlueOptics Atto CBL-0130-001 kompatibilný 40G QSFP+ pasívny Direct Attach medený kábel 1m

The BlueOptics Atto CBL-0130-001 compatible Direct Attach Cable (DAC) is a high-performance passive 40 Gigabit Twinaxial Copper solution designed for reliable connectivity within racks and across adjacent racks. Featuring QSFP+ connectors on both ends, this cable delivers 40 Gbps data rates with ultra-low power consumption, making it an ideal choice for data center interconnects, server-to-switch links, and high-speed networking environments.

Advantages

This passive DAC cable offers a cost-effective and energy-efficient alternative to active optical cables or transceivers. With zero power consumption (less than 0.1W), it reduces overall system power draw and heat generation. The twinaxial copper construction ensures low latency and high signal integrity over short distances, while the hot-swappable QSFP+ connectors enable easy installation and maintenance without network downtime.

Suitable for

• Data center rack-to-rack and rack-to-switch connections
• Server-to-switch and switch-to-switch links in 40G networks
• High-performance computing (HPC) clusters
• Storage area networks (SAN) requiring low-latency copper interconnects

Key specifications

• Data Rate: 40 Gbps
• Cable Type: Passive Direct Attach Copper (DAC)
• Connectors: QSFP+ to QSFP+
• Cable Length: 1 meter (3.28 feet)
• Cable Material: Twinaxial Copper
• Standard: IEEE 802.3ba 40GBASE-CR4
• Power Consumption: < 0.1W (Passive)
• Impedance: 100 Ohm
• Operating Temperature: 0°C to 70°C (32°F to 158°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Voltage: 3.3V
• Compliance: RoHS, CE, FCC

Recommendations

For optimal performance, ensure that both connected devices support 40GBASE-CR4 and QSFP+ interfaces. This cable is compatible with BlueOptics Atto CBL-0130-001 and similar QSFP+ ports. Always handle with care to avoid damaging the connectors or cable jacket.
