Cimco 187217 dutinka 1,5 mm² čiastočne izolovaná červená 100 ks

For terminating fine-stranded conductors, this Cimco wire end sleeve offers a funnel-shaped entry that guides individual wires into the tin-plated copper barrel without catching. The red polypropylene collar is partially insulated, leaving the metal sleeve exposed for a secure crimp connection.

Highlights

• Partially insulated design for reliable crimping
• Funnel-shaped entry simplifies insertion of fine-stranded conductors
• Tin-plated electrolytic copper barrel resists corrosion
• Red polypropylene collar for easy size identification
• Pack of 100 pieces

In daily use

The 1.5 mm² cross-section suits common control cabinet and field wiring tasks. The sleeve length of 8 mm provides ample contact area, while the overall length of 17 mm keeps the assembly compact. The insulation is rated UL 94 V-2 for flammability.

Full specifications

• Product type: Wire end sleeve (ferrule)
• Nominal cross-section: 1.5 mm²
• Colour: Red
• Insulation type: Partially insulated
• Material (ferrule): Electrolytic copper, tin-plated
• Material (insulation): Polypropylene (PP)
• Overall length: 17 mm
• Sleeve length (metal part): 8 mm
• Inner diameter (metal sleeve): 1.8 mm
• Outer diameter (insulation): 3.5 mm
• Temperature range: -40°C to +105°C
• Voltage rating: 600 V
• Flammability rating (insulation): UL 94 V-2
• Conductor compatibility: Fine-stranded conductors
• Standard compliance: DIN 46228 Part 4
• Environmental compliance: RoHS compliant

Final note

Supplied in a pack of 100, these sleeves are ready for high-volume wiring work.
