Optický kábel Sacon LSD31100030 3m ADSS

The Sacon LSD31100030 3m ADSS fibre optic cable uses OM3 multimode technology and SC connectors on both ends to provide a 3-metre connection with a 50 µm core diameter. Designed for full duplex communication, this cable supports high bandwidth data transmission with low attenuation over short to medium distances. The cable's ADSS (All-Dielectric Self-Supporting) construction is intended for environments where a self-supporting fibre run is required without the use of metallic strength members.

Advantages

The OM3 multimode core with 50 µm diameter enables higher modal bandwidth compared with lower-grade multimode fibres, supporting faster data rates for compatible equipment. SC connectors on both ends provide a standardised push-pull connection for easy mating with common network ports and patch panels. The ADSS design allows the cable to be installed on poles or between structures without electrical conductivity concerns, reducing the need for additional grounding or bonding. The 3 m length offers a ready-made patch or jumper solution for short links in server rooms, telecom cabinets, or campus installations.

Suitable for

• Short-run connections between network devices, switches or patch panels
• Server rack and cabinet internal fibre connections
• Campus or building backbone segments requiring OM3 multimode performance
• Self-supporting spans in non-conductive aerial installations

Key specifications

• Length: 3 m
• Fibre type: OM3 multimode
• Core diameter: 50 µm
• Connector type: SC to SC
• Communication: Full duplex
• Construction: ADSS (All-Dielectric Self-Supporting)

How to use

Connect each SC connector to the corresponding SC port on your devices, patch panels, or transceivers, ensuring proper alignment and a secure push-pull engagement. Verify the transceiver type and the port compatibility for multimode OM3 fibre and confirm that equipment supports full duplex operation. Route the cable to avoid sharp bends and mechanical stress; maintain the minimum bend radius recommended by your equipment or fibre manufacturer. For aerial or self-supporting installations, follow local regulations and standard practices for ADSS mounting and tensioning.

Recommendations

Before installation, inspect connector endfaces for contamination and clean them with appropriate fibre optics cleaning tools if needed. Use strain relief where the cable enters enclosures or equipment to prevent undue stress on the fibre, and label both ends to identify the link during maintenance. For distances and data rates beyond OM3 multimode capabilities, evaluate singlemode or higher-grade multimode solutions.
