Eaton 266119 predlžovacia hriadeľ pre PXL otočné pohony, 100 mm, štvorec 6x6 mm, oceľ

When a rotary operating mechanism sits too deep inside a panel or enclosure, the standard shaft cannot reach the door handle. The Eaton 266119 extension shaft solves this by adding 100 mm of length, bridging the gap between the mechanism and the external operator.

Who is it for

Panel builders and maintenance technicians working with Eaton NZM circuit breakers in industrial or commercial installations. It suits applications where the breaker is mounted far behind the door, such as deep distribution boards or custom enclosures.

Main features

• Extends the operating shaft by 100 mm for deeper panels
• Square 6 x 6 mm profile matches PXL rotary mechanisms
• Made of steel for reliable torque transmission
• Plug-in mounting without additional tools
• Compatible with Eaton NZM series breakers (NZM1–NZM4)

Specifications

• Accessory type: Extension shaft
• Product series: PXL
• Compatibility: External rotary operating mechanisms for Eaton NZM series
• Shaft length: 100 mm
• Shaft profile: Square
• Shaft cross-section: 6 x 6 mm
• Material: Steel
• Finish: Metallic (natural steel)
• Insulation: Non-insulated
• Application: Door/panel mounting extension
• Mounting type: Insert/plug-in

Tips

Verify the required extension length before ordering; multiple shafts can be combined if additional reach is needed. Ensure the shaft is fully seated in the coupling to avoid play.
