Eaton FAZ-C1/1 istič typu C, 1 A, 1-pólový, 10 kA, DIN lišta 278546

Protect your electrical circuits from overload and short-circuit currents with the Eaton FAZ-C1/1 miniature circuit breaker. This 1-pole, Type C MCB is designed for reliable protection in residential, commercial, and industrial installations.

Who is it for

Electricians, panel builders, and facility managers who need a dependable circuit breaker for lighting and control circuits with moderate inrush currents. Ideal for DIN rail mounting in distribution boards and control panels.

Main features

• Rated current: 1 A, 1-pole, Type C tripping characteristic
• Breaking capacity: 10 kA according to EN 60898
• Rated voltage: 230/400 V AC, 50/60 Hz
• DIN rail mounting (EN 60715) with screw terminals for 1–25 mm² conductors
• Clear ON/OFF position indicator for easy status identification

Specifications

• Series: FAZ
• Number of poles: 1
• Tripping characteristic: C
• Rated current: 1 A
• Rated voltage: 230/400 V AC
• Frequency: 50/60 Hz
• Breaking capacity: 10 kA
• Mounting: DIN rail
• Terminal capacity: 1–25 mm² (solid and flexible)
• Degree of protection: IP20 (terminals), IP40 (front when installed)
• Operating temperature: -25 to +75 °C
• Storage temperature: -40 to +80 °C
• Electrical life: >10,000 operations
• Mechanical life: >20,000 operations
• Energy limiting class: 3
• Standards: EN 60898, IEC 60898

Tips

Ensure the breaker is installed by a qualified electrician and that the circuit is de-energized before installation. For optimal protection, verify that the conductor cross-section matches the terminal capacity.
