EATON FAZ-C16/3 16 A 3-pólový istič s charakteristikou C

The EATON FAZ-C16/3 stands apart from conventional miniature circuit breakers by combining a compact 3-pole design with a precise C-curve trip characteristic, making it a dependable choice for protecting motor and transformer circuits against overloads and short circuits. Its 10 kA breaking capacity and energy limiting class 3 ensure robust performance in demanding industrial and commercial installations.

Highlights

• 16 A rated current with C tripping characteristic (5–10 × In) for inductive loads
• 3-pole configuration for three-phase circuits up to 400 V AC
• High 10 kA rated breaking capacity (Icn) per IEC/EN 60898-1
• DIN rail mounting with IP20 terminal protection
• Wide operating temperature range from -25 °C to +75 °C
• Long electrical and mechanical life: >10,000 and >20,000 operations

In daily use

Installed on a standard DIN rail, the FAZ-C16/3 provides reliable protection for motors, pumps, and control circuits. Its C-curve allows for inrush currents without nuisance tripping, while the 10 kA breaking capacity handles high fault currents safely. The screw terminals accept solid or stranded conductors from 1 to 25 mm², and the clear ON/OFF indicator simplifies status checks. With IP20 protection at the terminals, it is suitable for distribution boards and control panels where accidental contact is prevented.

Full specifications

• Brand: EATON
• Model: FAZ-C16/3
• MPN: 278873
• EAN: 4015082788735
• Number of poles: 3
• Tripping characteristic: C
• Rated current (In): 16 A
• Rated voltage (Ue): 400 V AC
• Rated breaking capacity (Icn): 10 kA
• Frequency: 50/60 Hz
• Mounting type: DIN rail
• Energy limiting class: 3
• Standards compliance: IEC/EN 60898-1
• Terminal capacity (solid/stranded): 1–25 mm²
• Degree of protection (terminals): IP20
• Electrical life: >10,000 operations
• Mechanical life: >20,000 operations
• Ambient operating temperature: -25 °C to +75 °C
• Short-circuit release range: 5–10 × In
• Rated impulse withstand voltage (Uimp): 4 kV
• Rated insulation voltage (Ui): 440 V

Final note

For reliable three-phase circuit protection with a C-curve, the EATON FAZ-C16/3 delivers consistent performance and compliance with international standards, backed by EATON's engineering expertise.
