EATON HN-C20/3 istič MCB, 20A, 3-pólový, C-charakteristika, 6kA

The EATON HN-C20/3 is a high-quality miniature circuit breaker (MCB) from the HN series, designed for reliable overcurrent protection in residential, commercial, and industrial electrical installations. With a rated current of 20 A and a tripping characteristic C, it provides optimal protection for circuits with moderate inrush currents, such as lighting and motor loads. The 3-pole configuration ensures simultaneous disconnection of all phases, enhancing safety and system integrity.

Advantages

This MCB offers robust thermal-magnetic protection against overloads and short circuits, with a breaking capacity of 6 kA according to IEC/EN 60898-1. Its compact 3-module design (52.5 mm) saves space on DIN rail mountings. The screw terminals accommodate conductors up to 25 mm², ensuring secure connections. With IP20 terminal protection and IP40 front protection, it is suitable for use in distribution boards and enclosures.

Suitable for

• Overcurrent protection in lighting circuits, socket outlets, and small motor loads
• Residential and commercial distribution boards
• Industrial control panels requiring reliable circuit protection

Key specifications

• Product Type: Miniature Circuit Breaker (MCB)
• Series: HN
• Number of Poles: 3
• Rated Current (In): 20 A
• Tripping Characteristic: C
• Rated Short-Circuit Breaking Capacity (Icn): 6 kA
• Rated Operational Voltage (Ue): 230/400 V AC
• Rated Insulation Voltage (Ui): 440 V AC
• Frequency: 50/60 Hz
• Mounting Type: DIN Rail (EN 60715)
• Terminal Type: Screw Terminals
• Terminal Capacity: 1-25 mm² (Solid/Stranded)
• Degree of Protection: IP20 (Terminals), IP40 (Front)
• Standard: IEC/EN 60898-1
• Module Width: 3 Modules (52.5 mm)
• Operating Temperature Range: -25 to +50 °C
• Energy Limiting Class: 3
• Release Type: Thermal-magnetic

Recommendations

For optimal performance, ensure the MCB is installed by a qualified electrician and used within its specified ratings. Always verify compatibility with your system voltage and load characteristics.
