Eaton PN1-100 odpojovač 1-pólový 100A DIN lišta 259141

The Eaton PN1-100 is a 1-pole disconnector switch rated at 100 A, designed for reliable isolation and switching in low-voltage electrical installations. Its compact DIN rail mounting and high terminal capacity make it suitable for industrial and commercial distribution boards.

Advantages

High current rating of 100 A in a single module width (18 mm) saves space on the DIN rail. The switch supports rigid conductors up to 70 mm² and flexible up to 50 mm², allowing versatile wiring options. With a mechanical life of 20,000 cycles, it ensures long-term durability.

Suitable for

• Main switch in distribution boards
• Isolation of circuits for maintenance
• Industrial control panels
• Commercial electrical installations

Key specifications

• Number of poles: 1
• Rated current: 100 A
• Rated operational voltage: 230/400 V AC
• Rated insulation voltage: 440 V
• Rated impulse withstand voltage: 4 kV
• Mounting: DIN rail
• Module width: 1 TE (18 mm)
• Terminal capacity: 1.5 - 70 mm² rigid, 1.5 - 50 mm² flexible
• Degree of protection: IP20 terminals, IP40 front
• Standard: IEC/EN 60947-3
• Operating temperature: -25 to +50 °C
• Conditional short-circuit current: 10 kA (with 100A gG fuse)
• Electrical life: 10,000 cycles
• Mechanical life: 20,000 cycles

Recommendations

For safe isolation and switching of high-current circuits in a compact form factor, the Eaton PN1-100 is a dependable choice for professional electricians.
