Eaton PXL-C13/3 13 A 3-pólový istič (MCB) s charakteristikou C 6 kA 236424

The Eaton PXL-C13/3 is a 3-pole miniature circuit breaker (MCB) with C-curve tripping characteristic, rated at 13 A and 230/400 V AC. Its 6 kA breaking capacity ensures reliable protection against overloads and short circuits in residential and commercial installations.

Advantages

This MCB offers precise protection with a C-curve, ideal for circuits with moderate inrush currents. It features a compact 3-module width (52.5 mm) for DIN rail mounting and screw terminals for secure connections. The red/green contact position indicator provides clear status at a glance.

Suitable for

• Protection of lighting and socket circuits in residential and commercial buildings
• Control circuits with moderate inductive loads
• DIN rail distribution boards (EN 60715)

Key specifications

• Rated current: 13 A
• Number of poles: 3
• Tripping characteristic: C
• Rated voltage: 230/400 V AC
• Breaking capacity: 6 kA (IEC/EN 60898-1)
• Frequency: 50/60 Hz
• Mounting: DIN rail
• Degree of protection: IP20 (terminals)
• Terminal type: screw
• Energy limiting class: 3
• Module width: 3 TE (52.5 mm)
• Operating temperature: -25 to +50 °C
• Connection capacity: 1-25 mm² (solid), 1-16 mm² (flexible)
• Overvoltage category: III
• Pollution degree: 2
• Mechanical life: >20,000 operations
• Electrical life: >10,000 operations
• Contact position indicator: red/green

Recommendations

For reliable circuit protection in demanding environments, pair this MCB with an appropriate residual current device (RCD) to ensure comprehensive safety.
