Eaton PXL-C16/2 istič, 2-pólový, 16 A, charakteristika C, 6 kA 236289

Electricians and panel builders use the Eaton PXL-C16/2 to protect branch circuits in commercial and industrial distribution boards. This two-pole miniature circuit breaker interrupts overload and short-circuit currents on both poles simultaneously, making it suitable for single-phase 230 V and three-phase 400 V systems.

Key specifications

• Rated current: 16 A
• Tripping characteristic: C-curve
• Number of poles: 2
• Rated voltage: 230/400 V AC
• Rated short-circuit breaking capacity: 6 kA
• Frequency: 50/60 Hz
• Mounting: DIN rail (EN 60715)
• Energy limiting class: 3
• Standard: IEC/EN 60898-1
• Terminal capacity: 1–25 mm² (solid/stranded), 1–16 mm² (fine-stranded)
• Operating temperature: -25 °C to +75 °C
• Mechanical life: >20,000 operations
• Electrical life: >10,000 operations
• Pollution degree: 2
• Overvoltage category: III
• Release type: thermal-magnetic
• Installation depth: 70 mm

Why choose it

The C-curve handles moderate inrush currents from motors, transformers, and lighting loads without nuisance tripping, while the 6 kA breaking capacity covers most residential and commercial applications. The compact PXL design saves space on the DIN rail and simplifies wiring with large, clearly marked terminals.

Ideal use cases

• Protection of socket outlets and lighting circuits in distribution boards
• Branch circuit protection for small motors and control circuits
• Use as a main switch for sub-distribution panels

Good to know

The PXL series is part of Eaton's xPole portfolio and is designed for easy installation and reliable performance in accordance with IEC/EN 60898-1.
