EATON PXL-C25/1 istič 25A 1P charakteristika C (236061)

The EATON PXL-C25/1 is a 1-pole miniature circuit breaker (MCB) with a rated current of 25 A and C-trip characteristic. Engineered for reliable protection of electrical installations against overloads and short circuits, this compact breaker fits standard DIN rails and is ideal for residential, commercial, and industrial applications.

Advantages

With a high breaking capacity of 10 kA and a wide ambient temperature range, the PXL-C25/1 ensures dependable performance in demanding environments. Its screw terminals accommodate conductors up to 25 mm², simplifying installation. The C-curve design is perfect for circuits with inrush currents, such as motor loads and transformers.

Suitable for

• Overcurrent protection in distribution boards
• Circuits powering inductive loads (motors, pumps, fans)
• Commercial and industrial electrical panels
• Residential consumer units requiring C-curve protection

Key specifications

• Rated current (In): 25 A
• Number of poles: 1
• Tripping characteristic: C
• Rated voltage AC: 230/400 V
• Rated breaking capacity (Icn): 10 kA (EN 60898)
• Frequency: 50/60 Hz
• Mounting: DIN rail (EN 60715)
• Terminal capacity: 1–25 mm² (solid/stranded)
• Protection: IP20 (terminals), IP40 (in enclosure)
• Standards: EN 60898, IEC 60898
• Electrical life: >10,000 operations
• Mechanical life: >20,000 operations
• Ambient temperature: -25 °C to +75 °C
• Module width: 1 module (17.5 mm)

Recommendations

Always verify the breaking capacity and trip curve match the installation requirements. For circuits with high inrush currents, the C-curve prevents nuisance tripping. Ensure proper mounting and torque settings per the manufacturer’s guidelines.
