Eaton PXL-C6/2 istič (MCB), 2-pólový, 6 A, charakteristika C, 6 kA, 230/400 V AC 236278

The Eaton PXL-C6/2 stands out as a compact 2-pole miniature circuit breaker with a C tripping characteristic, tailored for protecting circuits with moderate inrush currents such as lighting and socket outlets. Its 6 A rating and 6 kA breaking capacity make it a reliable choice for residential and commercial distribution boards.

Highlights

• 2-pole MCB with C-curve, 6 A rated current
• Rated voltage 230/400 V AC, frequency 50/60 Hz
• Short-circuit breaking capacity 6 kA, energy limitation class 3
• DIN rail mounting (EN 60715), width 2 modules (35 mm)
• Terminal capacity 1-25 mm², IP20 protection (terminals)

In daily use

Installed on a standard DIN rail, the PXL-C6/2 occupies just two modules, saving space in the distribution board. Its screw terminals accept solid or stranded conductors from 1 to 25 mm², enabling secure connections. The toggle switch provides clear ON/OFF indication, and the device is designed for 10,000 electrical and 20,000 mechanical operations, ensuring long service life.

Full specifications

• Current rating: 6 A
• Number of poles: 2
• Tripping characteristic: C
• Rated voltage: 230/400 V AC
• Breaking capacity: 6 kA
• Frequency: 50/60 Hz
• Energy limitation class: 3
• Mounting: DIN rail (EN 60715)
• Terminal capacity: 1-25 mm²
• Degree of protection: IP20 (terminals), IP40 (front, when installed)
• Electrical endurance: 10,000 operations
• Mechanical endurance: 20,000 operations
• Standards: EN 60898-1, IEC 60898-1
• Modular width: 2 modules (35 mm)
• Operating temperature: -25 to +50 °C

Final note

With its robust construction and compliance with international standards, the Eaton PXL-C6/2 delivers dependable circuit protection for modern electrical installations.
