EXERTIS CONNECT LC/UPC na LC/UPC OM4 duplex LWL patch kábel, 1m, LSZH, Erika Violet 392781

Fiber optic patch cable with LC/UPC to LC/UPC connectors, engineered for high-speed multimode networking. Delivers OM4 performance with 50/125 µm core, supporting data rates up to 100 Gbps over short distances. The 1.0 m length is ideal for patching within racks and between adjacent equipment, while the 2.0 mm duplex LSZH jacket ensures safety in dense installations.

Advantages

OM4 fiber provides extended reach for 10G, 40G, and 100G Ethernet compared to OM3, making it future-ready for bandwidth-intensive applications. The snagless connector design prevents damage during installation and maintenance, and the halogen-free LSZH jacket emits low smoke and no toxic halogens in case of fire, meeting strict safety regulations. Erika violet color coding simplifies identification of OM4 cables in crowded patch panels.

Suitable for

• Data centers and server rooms requiring high-density fiber patching
• Enterprise backbone connections between switches, routers, and storage
• Telecommunications rooms and campus network links
• Any environment where low smoke and halogen-free materials are mandated

Key specifications

• Connector type: LC/UPC male to LC/UPC male
• Fiber type: Multimode OM4, 50/125 µm core/cladding
• Cable length: 1.0 m
• Fiber count: Duplex (2 fibers)
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Cable diameter: 2.0 mm
• Insertion loss: ≤ 0.25 dB
• Return loss: ≥ 35 dB
• Wavelength support: 850 nm, 1300 nm
• Bandwidth (850 nm): 4700 MHz·km
• Max data rate: 100 Gbps (up to 100 m at 850 nm)
• Compliance: RoHS, REACH

Recommendations

For mission-critical fiber links, pair this cable with OM4-compatible transceivers and maintain proper bend radius to ensure optimal performance. Verify connector cleanliness before each connection to avoid signal degradation.
