EXSYS EX-11081-2 PCIe USB 3.2 Gen 1 karta s 1+1 portami (Renesas)

The EXSYS EX-11081-2 stands out by adding four USB 3.2 Gen 1 ports through a single PCIe x1 slot, with two ports accessible from the rear bracket and two more routed to a 19-pin header for front-panel or internal devices. This dual-layout approach gives system builders flexibility that typical USB expansion cards lack.

Highlights

• Renesas µPD720202 host controller ensures stable 5 Gbit/s operation and UASP support for faster storage transfers.
• Backward compatible with USB 2.0 and 1.1 devices, so older peripherals continue to work without issues.
• Low-profile design with both standard and low-profile brackets included fits slim desktops and 2U rackmount chassis.
• SATA power connector supplies up to 900 mA per port, enough for bus-powered external drives.

In daily use

Installing the card is straightforward: plug it into an available PCIe x1 slot, connect a SATA power cable, and the operating system loads the built-in xHCI driver. The two internal ports are ideal for connecting front-panel USB 3.0 hubs or internal card readers, while the rear ports handle external drives, cameras, and other high-speed devices. Hot-swap support lets you connect or disconnect devices without rebooting.

Full specifications

• Host interface: PCI Express x1 (PCIe 2.0)
• USB standard: USB 3.2 Gen 1 (USB 3.0 / USB 3.1 Gen 1)
• Maximum data transfer rate: 5 Gbit/s
• External ports: 2 x USB Type-A female
• Internal ports: 2 x USB Type-A female via 19-pin header
• Total ports: 4
• Chipset: Renesas µPD720202
• Power connector: 15-pin SATA power
• Form factor: Low profile PCI Express card
• Included brackets: Standard and low-profile
• Operating system support: Windows 7/8/8.1/10/11 (32/64-bit), Linux
• Backward compatibility: USB 2.0, USB 1.1
• UASP support: Yes
• Hot-swap support: Yes
• Plug & Play: Yes
• Max power output per port: 5V / 900mA
• Compliance: xHCI (eXtensible Host Controller Interface)

Final note

The EX-11081-2 is a practical way to modernize an older desktop with fast USB 3.2 Gen 1 connectivity, both inside and outside the case.
