f-tronic rozvodná svorka 63A 16mm² BKE-I16 s pripojovacími svorkami 7110603

In control cabinets, connecting a large incoming conductor to multiple smaller outgoing conductors without a reliable distribution point leads to messy wiring and potential safety risks. The f-tronic BKE-I16 distribution terminal block solves this by providing a single, robust junction for 63 A power distribution.

Who is it for

Electricians and panel builders who need a DIN-rail mountable terminal block to distribute power from a 16 mm² supply conductor to up to six 4 mm² load conductors in industrial or commercial installations.

Main features

• Rated current 63 A, rated voltage 400 V
• Input cross-section 1 x 16 mm², output cross-section 6 x 4 mm²
• Screw terminal connection for secure clamping
• Mounts on 35 mm DIN rail or with screws
• Grey plastic housing (RAL 7035), UL94 V-0 flammability rating

Specifications

• Product type: Distribution terminal block
• Number of poles: 1
• Rated impulse withstand voltage (Uimp): 4 kV
• Insulation voltage (Ui): 500 V
• Protection class: IP20
• Housing material: Plastic (PA6)
• Terminal material: Brass / Copper
• Operating temperature: -25°C to +70°C
• Standards: IEC/EN 60947-7-1

Tips

Ensure the terminal block is installed in an enclosure with appropriate protection against dust and moisture, as its IP20 rating is intended for indoor use only.
