Optický kábel Good Connections LW-S907LASA 7,5 m FTTH G.652D LC na SC žltý

Good Connections LW-S907LASA fibre optic cable, 7.5 m, is intended for FTTH and short in-building links. The cable uses single-mode G.652D fibre with a 9 µm core diameter and features an LC connector on one end and an SC connector on the other. A yellow outer jacket provides easy identification in access networks and patching environments while maintaining low-loss single-mode transmission suitable for connecting equipment and splice panels.

Advantages

The single-mode G.652D fibre provides low attenuation and stable signal transmission over typical access-network distances. The LC to SC connector pair offers a combination of compact LC termination and widely used SC interface compatibility. The 7.5 m length covers common patching and equipment-connection needs inside premises without excess slack. The yellow jacket simplifies identification of single-mode cabling runs in multi-cable installations.

Key specifications

• Fibre type: single-mode G.652D
• Core diameter: 9 µm
• Length: 7.5 m
• Connectors: LC (one end) to SC (other end)
• Jacket colour: yellow
• Application: FTTH, access networks, in-building patching

How to use

Route the fibre optic cable carefully to avoid tight bends and mechanical stress; maintain the minimum bend radius recommended for single-mode G.652D fibre. Insert the LC connector into the LC receptacle and the SC connector into the SC adapter or device port until each connector clicks into place. For permanent installations, verify connector end-face cleanliness before mating and use appropriate dust caps when connectors are not in use. After connection, test the link loss and optical continuity with suitable test equipment to confirm acceptable performance.

Recommendations

Handle connectors by the boot or connector body to avoid touching the ferrule. Clean connector end-faces with fiber-grade cleaning supplies before connecting. Avoid routing the cable near electrical noise sources and secure the cable to prevent strain; store spare length in gentle loops following recommended bend-radius guidelines.
