Hager universZ medená lišta ZM12C 12x5mm 2-polová 250A

The Hager ZM12C is a solid copper busbar designed for the universZ distribution board system, providing a reliable main or branch power distribution solution. Its 12 x 5 mm cross-section supports a rated current of 250 A, making it suitable for demanding electrical installations. Unlike modular busbars that require multiple connections, this single-piece bar ensures low resistance and consistent performance across two fields.

Highlights

• Solid copper construction for excellent conductivity
• 12 x 5 mm cross-section, rated for 250 A
• Designed for 2 fields in universZ distribution boards
• Uninsulated design for direct connection to busbar holders
• Length: 500 mm

In daily use

Installers appreciate the ZM12C for its straightforward integration into Hager universZ boards. The bar is screwable and compatible with standard busbar holders and terminals, ensuring a secure fit. Its solid copper material minimizes voltage drop and heat generation, contributing to long-term reliability in residential and commercial applications.

Full specifications

• Product Type: Busbar
• Series: universZ
• Material: Copper (CU)
• Cross-section: 12 x 5 mm
• Number of Fields: 2
• Rated Current (Ith): 250 A
• Number of Poles: 1-pole
• Mounting Type: For universZ distribution boards
• Insulation: Uninsulated
• Length: 500 mm
• Width: 12 mm
• Thickness: 5 mm
• Colour: Copper metallic
• Connection Type: Screwable
• Design: Solid bar

Final note

A dependable power distribution component engineered for Hager universZ systems, delivering high current capacity in a compact form.
