LANCOM LX-6402 - rádiová základňová stanica - 802.11ac Wave 2, 802.11ax - Wi-Fi - dualband - AC 100 (61825)

The LANCOM LX-6402 is a dual-band access point that supports Wi‑Fi 6 (IEEE 802.11ax) for simultaneous operation in the 2.4 GHz and 5 GHz bands. It provides aggregated wireless data rates up to 3,550 Mbps and supports modern security protocols as well as Power over Ethernet (PoE) for flexible installation. The device includes four internal antennas, two Ethernet LAN ports and a compact white design suitable for office and public environments.

Advantages

The LANCOM LX-6402 delivers dual concurrent Wi‑Fi with an aggregated throughput of up to 3,550 Mbps, offering up to 2,400 Mbps in the 5 GHz band and up to 1,150 Mbps in the 2.4 GHz band. It supports 4x4 Multi‑User MIMO for both downlink and uplink to serve multiple clients efficiently and reduce latency. Professional IoT connectivity is provided via Bluetooth Low Energy 5.1 and a USB 3.0 port, enabling integration with sensors, digital signage and Wireless ePaper solutions. OFDMA improves spectrum efficiency by dividing channels into subcarriers, allowing small IoT packets to coexist with larger traffic. The access point supports 160 MHz channel width for higher throughput on compatible terminals and Target Wake Time (TWT) to reduce client power consumption. Band steering balances load by directing clients to the less congested 5 GHz band. The device can be managed centrally via the LANCOM Management Cloud or operated standalone with an intuitive WEBconfig interface for quick setup and monitoring.

Suitable for

• Small and medium-sized offices requiring high-performance wireless LAN
• Public areas such as reception, meeting rooms and lobbies
• Environments deploying IoT devices, digital signage or electronic shelf labels
• Installations that require PoE and easy cloud-based management

Key specifications

• Wireless standard: IEEE 802.11ax (Wi‑Fi 6), dual-band 2.4 GHz and 5 GHz
• Aggregate wireless datarate: up to 3,550 Mbps (2,400 Mbps @5 GHz + 1,150 Mbps @2.4 GHz)
• MU‑MIMO: 4x4 for downlink and uplink
• OFDMA and TWT support
• Channel widths: 20/40/80 MHz (4 streams), 160 MHz (2 streams)
• Bluetooth Low Energy 5.1 and USB 3.0 for IoT integration
• Ethernet LAN ports: 2 (RJ‑45), supports PoE
• Antennas: 4 (internal)
• Color: White

How to use

Connect the LANCOM LX-6402 to a PoE-enabled switch or provide power via a compatible adapter, then connect the uplink to your network. For cloud-managed setups, register the device in the LANCOM Management Cloud and apply your configuration profile for SSIDs, security (WPA2/WPA3) and network policies. For standalone use, access the WEBconfig interface through a web browser to perform initial setup, configure SSIDs, band steering and QoS, and monitor client connections via the dashboard. Optionally connect IoT devices via Bluetooth Low Energy or USB for Wireless ePaper and other sensor-based applications.

Recommendations

Position the access point centrally in the coverage area and avoid physical obstructions. Enable band steering and MU‑MIMO to improve client distribution and throughput. Use 160 MHz channels only where compatible client devices and local regulations permit, and enable TWT for battery-powered clients to extend device runtime.
