LANVIEW RP-TNC konektor samec na RP-TNC konektor samec LMR-240 FR kábel 3m

The LANVIEW LVN-RPTNC-MF-3M is a high-performance RF cable assembly featuring RP-TNC male connectors on both ends and a 3-meter length of LMR-240 FR (Flame Retardant) coaxial cable. Designed for reliable signal transmission in demanding environments, this cable is ideal for Wi-Fi, WLAN, cellular, GPS, and other RF systems.

Advantages

This cable offers excellent electrical performance with low attenuation, ensuring minimal signal loss over the 3-meter length. The flame retardant jacket enhances safety in installations where fire resistance is critical. Gold-plated connectors provide corrosion resistance and reliable connectivity.

Suitable for

• Wi-Fi and WLAN access points and antennas
• Cellular and GPS antenna extensions
• RF test and measurement setups
• Indoor and outdoor RF applications requiring flame retardant cabling

Key specifications

• Cable Type: LMR-240 FR (Flame Retardant)
• Connector 1: RP-TNC Male
• Connector 2: RP-TNC Male
• Cable Length: 3 meters (9.84 feet)
• Impedance: 50 Ohm
• Frequency Range: DC to 6 GHz
• Attenuation @ 2.4 GHz: 0.39 dB (approx.)
• Attenuation @ 5.8 GHz: 0.61 dB (approx.)
• Jacket Material: Flame Retardant Polyethylene (FR-PE)
• Connector Plating: Gold
• Operating Temperature: -40°C to +85°C
• RoHS Compliant

Recommendations

For optimal performance, use with 50 Ohm RF equipment and ensure connectors are properly torqued. Suitable for both indoor and outdoor use when properly sealed against moisture.
