LED driver MEAN WELL LPV-150-12

The MEAN WELL LPV-150-12 is a 150W class II single-output LED driver designed for constant-voltage LED lighting and LED moving sign applications. Housed in a UL 94V-0 flame-retardant plastic enclosure with an IP67 rating, this model is suitable for dry, damp and wet locations. It delivers a 12V constant-voltage output and accepts universal AC input from 180 to 305 VAC, operating reliably in temperatures from -25 °C to 65 °C. Its compact dimensions (63 mm × 191 mm × 37.5 mm) and 740 g weight make it suitable for installations with limited space.

Advantages

The LPV-150-12 provides a stable 12V constant-voltage output and offers protection against water and dust with an IP67 enclosure. The flame-retardant plastic housing meets UL 94V-0 requirements, and the driver supports wide AC input range (180–305 VAC) for use in varied mains environments. Its compact size and moderate weight simplify mounting and integration into lighting systems.

Suitable for

• Outdoor and indoor LED strip lighting
• LED moving signs and channel letter lighting
• Architectural and facade illumination in wet or damp locations
• Commercial lighting installations requiring 12V constant voltage

Key specifications

• Model: LPV-150-12
• Brand: MEAN WELL
• Output power: 150 W (single output, constant voltage)
• Output voltage: 12 V
• AC input: 180–305 VAC
• Operating temperature: -25 °C to 65 °C
• Ingress protection: IP67
• Enclosure: UL 94V-0 flame-retardant plastic
• Dimensions (W × D × H): 63 × 191 × 37.5 mm
• Weight: 740 g
• MPN: LPV-150-12
• EAN: 4021087026116

How to use

Install the LPV-150-12 in a location appropriate for its IP67 rating, ensuring cable entries and connectors are properly sealed for outdoor or wet environments. Connect the AC input to a suitable mains supply within 180–305 VAC and connect the 12V output to the LED load, observing correct polarity. Allow adequate ventilation and secure mounting to avoid mechanical stress. Follow local electrical codes and isolate mains power before wiring.

Recommendations

For longest service life, avoid continuous operation at maximum ambient temperature and ensure the load does not exceed the rated 150 W. Use correct cabling suitable for outdoor installations and consult MEAN WELL documentation for detailed installation and safety instructions.
