PoE napájací zdroj Extralink POE-24-24W-G 24 V 1 A 24 W Gigabit, interiérový, čierny, napájací kábel v balení

Extralink POE-24-24W-G is an indoor PoE power supply that provides 24 V DC at 1 A (24 W) and supports Gigabit Ethernet data transmission over the same twisted-pair cable used to deliver power. Housed in a compact black ABS enclosure with passive cooling, this PoE adapter includes an AC power cable and is intended for powering PoE-capable network equipment where a reliable 24 W DC source is required. The design enables simultaneous delivery of power and gigabit data without additional power injectors or separate power jacks.

Advantages

The Extralink POE-24-24W-G combines power delivery and gigabit network connectivity in a single device, reducing cabling complexity and installation time. Its passive PoE solution supports full gigabit throughput on compatible cables and eliminates the need for inline power jacks or external power supplies for devices designed to accept 24 V passive PoE. The compact ABS housing with passive cooling provides a low-noise, maintenance-free solution suitable for indoor installations, and the included AC power cable simplifies setup.

Suitable for

• Indoor access points that accept 24 V passive PoE
• IP surveillance cameras designed for 24 V passive PoE
• VoIP phones and small network devices requiring a 24 V, 1 A supply
• Network deployments where Gigabit Ethernet data and power must share one cable

Key specifications

• Output voltage: 24 V DC
• Output current: 1 A
• Maximum output power: 24 W
• Network support: Gigabit Ethernet over twisted-pair
• PoE type: passive PoE (non-IEEE 802.3at/af compliant)
• Enclosure material and colour: ABS, black
• Cooling method: passive
• Included accessories: AC power cable
• Intended use: indoor

How to use

Connect the included AC power cable to the Extralink POE-24-24W-G and plug it into a suitable mains outlet. Use a standard Ethernet cable to connect the PoE output of the adapter to the powered device’s Ethernet port; the same cable will carry both power and data when the connected device supports passive 24 V PoE and Gigabit speeds. Ensure the connected device is rated for 24 V passive PoE to avoid compatibility issues. Position the adapter indoors in a ventilated location away from heat sources and moisture.

Recommendations

Use high-quality Cat5e or Cat6 cabling and keep cable runs within recommended lengths to maintain gigabit performance and minimise voltage drop. Verify device compatibility with 24 V passive PoE before installation. For installations that require IEEE 802.3af/at compatibility or higher power budgets, choose an active PoE injector or switch that complies with the relevant standard.
