SCHELINGER SL8 LED signálna lampa žltá 230V AC montáž do rozvádzača IP65

With an exceptionally long lifespan exceeding 30,000 hours and a low current draw under 20 mA, the SCHELINGER SL8 yellow LED signal lamp delivers reliable, energy-efficient indication for industrial control panels and machinery. Its IP65 front protection and robust vibration resistance ensure dependable performance even in demanding environments.

Overview

The SCHELINGER SL8 is a panel-mount LED signal lamp with a 22 mm mounting diameter, designed for clear visual status indication in automation, control cabinets, and equipment. The lamp emits a bright yellow light from a long-life LED, ensuring high visibility and minimal maintenance. The black round bezel provides a professional appearance and secure panel mounting.

What stands out

• Ultra-long LED lifespan of over 30,000 hours reduces replacement frequency
• Low current consumption (<20 mA) for energy savings and reduced heat generation
• IP65 front protection against dust and water jets
• Wide operating temperature range from -25°C to +70°C
• High resistance to vibration (10-500 Hz) and shock (100 m/s²)
• Simple screw terminal connection for easy wiring

Technical details

• Light source: LED
• Light colour: Yellow
• Operating voltage: 230V AC
• Mounting diameter: 22 mm
• Terminal type: Screw terminals
• Protection rating (front): IP65
• Operating temperature: -25°C to +70°C
• Housing material: Plastic
• Lifespan: >30,000 hours
• Current consumption: <20 mA
• Dielectric strength: 2.5 kV AC
• Insulation resistance: >100 MΩ
• Vibration resistance: 10-500 Hz, 1.5 mm amplitude
• Shock resistance: 100 m/s²
• Certifications: CE, RoHS
• Mounting type: Panel mount
• Bezel shape: Round
• Bezel colour: Black
• Series: SL8

Our verdict

The SCHELINGER SL8 yellow LED signal lamp combines durability, efficiency, and clear visibility in a compact panel-mount design. It is an excellent choice for industrial applications requiring reliable status indication with minimal maintenance.
