Spínací aktor JUNG FM STD 8 UP

The JUNG FM STD 8 UP is a compact DIN-rail switching actuator for 230 V electrical installations, operating at 868 MHz and compatible with eNet radio systems. It supports AES-CCM encrypted radio transmission from eNet Server software version 2.0, offers switching and brightness control for DALI luminaires when used with a suitable interface, and can be mounted in an appliance box (DIN 49073), surface-mounted housing or with a mounting adapter for false ceilings.

Advantages

The actuator provides secure radio communication using AES-CCM encryption (with eNet Server v2.0), compact dimensions for space-saving installation (53 mm wide, 28 mm high) and reliable operation at mains voltage 230 V with 50/60 Hz. It supports operation with compatible eNet radio transmitters and allows integration with DALI luminaires for switching and dimming functions when a DALI interface is used.

Suitable for

Key specifications

How to use

Install the FM STD 8 UP in an appropriate appliance box (DIN 49073) or a suitable surface-mounted housing or adapter. Connect the supply voltage (230 V AC) and wiring to the switched outputs according to the installation diagram. Pair the actuator with compatible eNet radio transmitters and, if required, integrate it into an eNet Server system (version 2.0 or later) to enable AES-CCM encrypted radio communication. For DALI luminaires, connect the appropriate DALI interface to use switching and brightness control functions.

Recommendations

Use the actuator with approved eNet radio transmitters and keep eNet Server software updated to v2.0 or later to ensure encrypted radio communication. Mount in compliance with local electrical codes and follow the manufacturer wiring diagram; installation should be performed by a qualified electrician.
