Telegärtner L00005A0055 Cat.7 S/FTP sieťový kábel na meter, 10m, zelený, LSZH, 600MHz, 10GBase-T, 100Ω, AWG23

For fixed installations demanding uncompromised signal integrity, the Telegärtner L00005A0055 delivers Cat.7 performance in a bulk cable format that gives installers full control over termination. Unlike pre-terminated patch leads, this raw S/FTP cable is built for permanent horizontal runs where custom lengths and professional connectors are required. The green LSZH jacket not only aids identification in dense cable trays but also meets strict fire safety standards, making it suitable for public buildings and industrial environments.

Highlights

• Cat.7 performance up to 600 MHz, supporting 10GBASE-T Ethernet
• S/FTP construction: overall braided screen plus individual foil per pair for maximum alien crosstalk immunity
• Bare copper conductors, AWG 23, 4 pairs, 100 Ohm impedance
• Low Smoke Zero Halogen (LSZH) jacket in green, flame retardant to IEC 60332-1
• 10-meter bulk length, ideal for structured cabling, patch panel termination, or custom patch cords

In daily use

This cable is engineered for professional installers who need reliable, high-bandwidth backbone links. The S/FTP shielding provides excellent protection against electromagnetic interference, ensuring stable 10 Gigabit speeds even in electrically noisy environments. The robust LSZH sheath is easy to strip and handle, while the colour-coded green jacket simplifies network segmentation. Whether you are wiring a data centre, office floor, or industrial facility, this bulk cable gives you the flexibility to create exact-length runs with minimal waste.

Full specifications

• Cable type: Bulk network cable (raw, unterminated)
• Category: Cat.7
• Shielding: S/FTP (Screened/Foiled Twisted Pair) – overall braided screen, individual foil per pair
• Length: 10 m
• Colour: Green
• Conductor material: Bare copper
• Conductor gauge: AWG 23
• Number of pairs: 4
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Characteristic impedance: 100 Ω
• Frequency range: Up to 600 MHz
• Supported data rate: Up to 10 Gigabit Ethernet (10GBASE-T)
• Standards compliance: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2
• Flame retardancy: IEC 60332-1, IEC 61034, IEC 60754
• Outer diameter (nominal): Approx. 7.8 mm
• Application: Fixed installation, horizontal cabling
• PoE support: Yes, up to PoE++ (IEEE 802.3bt Type 3)
• Operating temperature: -20°C to +60°C

Final note

Telegärtner's L00005A0055 combines high-frequency performance with installation-friendly LSZH materials, making it a dependable choice for certified Cat.7 infrastructure projects.
