WAGO 209-105 Priechodná svorka, 2-vodičová, 2,5 mm², sivá, 50 kusov

The WAGO 209-105 is a high-quality through terminal block designed for reliable and maintenance-free electrical connections. Featuring the innovative CAGE CLAMP® connection technology, this terminal block ensures secure and vibration-resistant wiring for solid, stranded, and fine-stranded conductors. With a compact design and gray polyamide housing, it is ideal for use in control cabinets and industrial applications.

Advantages

• CAGE CLAMP® technology for fast, tool-free connection
• Vibration-proof and maintenance-free operation
• Rated voltage up to 800 V and rated current up to 24 A
• Suitable for conductors from 0.08 mm² to 4 mm² (AWG 28 to 12)
• Compact design saves space on DIN-rail (TS 35)
• Flammability rating UL94 V-0 for enhanced safety

Suitable for

• Industrial control systems
• Building automation
• Distribution boards
• Machine wiring

Key specifications

• Number of conductors: 2
• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool
• Nominal cross-section: 2.5 mm² (AWG 14)
• Solid conductor size: 0.08 - 4 mm² (28 - 12 AWG)
• Stranded conductor size: 0.08 - 4 mm² (28 - 12 AWG)
• Fine-stranded conductor size: 0.08 - 2.5 mm² (28 - 14 AWG)
• Nominal voltage (III/3): 800 V
• Rated surge voltage (III/3): 8 kV
• Nominal current: 24 A
• Connection type: Through terminal block
• Mounting type: DIN-rail (TS 35)
• Color: Gray
• Insulating material: Polyamide (PA 66)
• Flammability rating: UL94 V-0
• Pollution degree: 3
• Packaging quantity: 50 pieces

Recommendations

For optimal performance, use with WAGO operating tools and appropriate DIN-rail accessories. Ensure proper conductor stripping and insertion for reliable connections.
