BlueOptics FTCC8612E2PCM kompatibilný QSFP56 200GBASE-SR4 transceiver MPO-12 850nm 100m

The BlueOptics FTCC8612E2PCM compatible QSFP56 transceiver delivers high-performance 200 Gigabit Ethernet connectivity for data centers and enterprise networks. Designed for multi-mode fiber applications, this hot-pluggable module supports 200GBASE-SR4 standard with MPO-12 connector, enabling reliable data transmission up to 100 meters over OM4 fiber.

Advantages

Cost-effective alternative to OEM modules with full compatibility and performance. Low power consumption under 4.5W reduces operational costs. Supports Digital Diagnostic Monitoring (DDM) for real-time performance tracking. Compliant with IEEE 802.3cd and InfiniBand protocols, ensuring seamless integration.

Suitable for

• Data center interconnects
• High-performance computing clusters
• Enterprise network backbone
• Open network platforms (e.g., FTCC8612E2PCM)

Key specifications

• Form Factor: QSFP56
• Data Rate: 200 Gbps (4x 50Gbps PAM4)
• Transceiver Type: 200GBASE-SR4
• Wavelength: 850 nm
• Max Distance: 100m (OM4 MMF)
• Fiber Type: Multi-Mode (MMF)
• Connector: MPO-12
• Power Consumption: < 4.5W
• Operating Temperature: 0°C to 70°C
• Hot-Pluggable: Yes
• DDM/DOM: Yes
• Standards: IEEE 802.3cd, InfiniBand

Recommendations

For optimal performance, use with OM4 multi-mode fiber and ensure proper MPO connector cleaning. Compatible with switches and routers supporting QSFP56 200G ports. Ideal for high-bandwidth applications requiring low latency and high reliability.
